| Silo ? |
 |
Among various conveying methods for powder, the pneumatic conveying method is widely used for as a conveying facility for powder because of its flexible conveying passage and a large conveying capacity per unit area of a facility. We, Hansung Corp., offer high-quality facilities based on our excellent technologies and accumulated know-how at sites. |
|
The pneumatic conveying method can be divided into two types; High Speed & Low Density Conveying Type and Low Speed & High Density Conveying Type. We usually select the high speed & low density conveying type, which can be divided into the low pressure feed type, the suction tyoe and high pressure feed type. |
|
|
 |
| Types and Features |
| Types |
Figures |
Equations |
Features |
Uses |
Leg Type
(Structure) |
 |
H=2.5D
S=D
H+S=3.5D |
Most General Type
Supported by Leg |
General Independent Type
Metal Plates Storage
Chemical Industry |
| Skirt Type |
 |
H=2.5D
S=D
H+S=3.5D |
Supported by Long Skirt |
Grain Storage
Chemical Industry
Concrete Storage |
| Skirt Type |
 |
H=D |
Height = Diameter |
Large Scaled Storage of Powder
such as Cement and Alumina |
|
|
| Considerations for Design |
|
Storage Amount, Required Material, Ground Intensity, Bearing Capacity, Structure of Powder & Particles Granularity, Real Specific Gravity, Apparent Specific Gravity, Temperature, Moisture Absorbability, Adhesiveness, Sensitivity, Chargeability, Explosiveness, Abrasiveness, Crushability, Scattering Property, Poisonousness, Corrosiveness, Angle of Repose, Angle of Friction, Liquidity |
|
Types of Storage Tank (Load and Snow Cover) and Auxiliary Facilities, Load Operational Condition (Operational Pressure and Temperature), Conditions for Feed and Discharge, Necessity and Kinds of Silo Accessories, Kinds and Counterplans of Accidents in Case |
|
| SPECIFICATION |
| Model |
Size |
Capat
(㎥) |
Roof |
Shell |
Cone |
기타
(kg) |
SUS
소계
(kg) |
C.S
소계
(kg) |
Total
Weight
(kg) |
| Dia. (m) |
Shell (m) |
t (mm) |
w (kg) |
T (mm) |
W (kg) |
T (mm) |
W (kg) |
| HSSO-5 |
1.80 |
2.10 |
5 |
4 |
144 |
4 |
452 |
4 |
288 |
88 |
972 |
158 |
1,130 |
| HSSO-10 |
2.00 |
3.20 |
10 |
4 |
178 |
4 |
765 |
4 |
355 |
130 |
1,428 |
260 |
1,688 |
| HSSO-30 |
2.20 |
7.50 |
30 |
5 |
269 |
5 |
2,466 |
5 |
537 |
327 |
3,600 |
355 |
3,955 |
| HSSO-50 |
2.70 |
8.00 |
50 |
5 |
405 |
5 |
3,229 |
5 |
809 |
444 |
4,887 |
429 |
5,316 |
| HSSO-80 |
3.00 |
9.50 |
80 |
5 |
500 |
5 |
4,260 |
5 |
999 |
576 |
6.335 |
473 |
6,808 |
| HSSO-100 |
3.25 |
10.50 |
100 |
5 |
586 |
6 |
6,121 |
5 |
1,173 |
788 |
8,668 |
510 |
9,178 |
| HSSO-150 |
3.50 |
13.00 |
150 |
5 |
680 |
6 |
8,161 |
5 |
1,360 |
1,020 |
11,222 |
1,169 |
12,391 |
| HSSO-200 |
3.80 |
15.00 |
200 |
5 |
802 |
6 |
10,224 |
5 |
1,603 |
1,263 |
13,892 |
1,261 |
15,153 |
|
|
|
|
